Notes and examples in mechanics; with an appendix on the graphical statics of mechanism; (1903)
Church, Irving P. (Irving Porter), 1851-1931 · New York, J. Wiley & sons; [etc., etc.] · leaf 40
Fig. 30. Fig. 31. straight links, if we wish to consider free the portion on theleft of the imaginary cutting surface A , . B^ the system of forcesacting on the ideal body so obtained (see Fig. 31) consists of theabutment reaction Y^, the loads G^ G\ and G (at the joints<z, 5, and c\ and the…
