Notes and examples in mechanics; with an appendix on the graphical statics of mechanism; (1903)
Church, Irving P. (Irving Porter), 1851-1931 · New York, J. Wiley & sons; [etc., etc.] · leaf 51
Fig. 51. and is compression, as assumed. … 42 NOTES AND EXAMPLES IN MECHANICS. In Fig. 4^ we note that since pieces C and D are in the samestraight line and G is the onlj other piececonnecting with the joint -m (there being alsono load on ???), the stress in the piece G mustbe zero and the stress in G must equal that inD ; similarly, the…
