Wallis, Rolland S. [from old catalog], Iowa state college of agriculture and mechanic arts, Ames. Dept. of engineering extension. [from old catalog] · Ames, Iowa, Engineering extension department, Iowa state college · leaf 49
Fig. 63.—Two methods of finding points on the line of intersection of two cylinders. … (b) (c) (e) (f) Fig. 64. Two methods of finding points on the line of intersection of a cone and a cylinder. Working Drawings A complete working drawing carries all the dimensions and other in-formation that the workman needs in forming or finishing the piece orstructure. It should not be necessary…
Mechanical drawing
