Rollins, William Herbert, 1852-1929 · Boston : The University Press · leaf 446
NOTES 16 AND 17 —FIGURE 2 —X-LIGHT TUBEIN WHICH THE TARGET IS PLACED BE-TWEEN THE ANODE AND THE CATHODE.THE TARGET CAN BE MADE AN ANODE,WHEN DESIRED, BY CONNECTING IT BY AWIRE WITH THE ANODE Plate 6 … NQTE 19 — FIGURE C —COOLED TARGETX-LIGHT TUBE WITH MOVABLE CATHODE Plate 7 OUTLET FOR .WASTE WATER- SOFT RUBBER] FIGURES D AND Di NOTE 19 —DIRECT ACTING X-LIGHT TUBESWITH DIAPHRAGMS TO LIMIT THE RADI-ANT AREAS TO INSURE SHARP DEFINI-TION, AND WITH COOLED TARGETS TOALLOW LARGE AMOUNTS OF ENERGY TOBE…
X-rays · Phototherapy
