Notes on X-light (1903)
Rollins, William Herbert, 1852-1929 · Boston : The University Press · leaf 474
NOTE 36 —FIGURE 34 —NON-RADIABLEX-LIGHT TUBE BOX WITH CENTRING DIA-PHRAGM PLATE Plate 12 … XB^=*i=»- NOTE 35 —FIGURES 32 AND 33 —COVERING THEPLATINUM TARGET WITH ALUMINUM NOTE 36 — FIGURES 35, 36, AND 37 — DIFFERENTPOSITIONS FOR THE NON-RADIABLE TUBEBOX SHOWN IN PLATE 12 NOTE 37 —FIGURE 38A —COOLING THE TAR-GET OF AN X-LIGHT TUBE WITH EXTERNALMETAL VANES Plate 13 Aluminum CellX-rays · Phototherapy
Internet Archive · Medical Heritage Library · Public Domain Mark 1.0. Free to use for anything.
