Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 93

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 93
nk lever M, L, and by its actioncontrols the throttle valve. 306. GOVERNOR FOR A STEAM ENGINE (old).—A revolving spindle, a, carries with it a pair ofcylindrical inclined planes, d. The ball b, frameand wings c, slide freely upon an extension ofthe spindle. The varying air resistance given tothe…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
