Notes on X-light (1903)

Rollins, William Herbert, 1852-1929 · Boston : The University Press · leaf 492

An illustration from Notes on X-light, 1903, leaf 492 — NOTE 48 —FIGURE 48 — REFLECTING CRYPTO-SCOPE AND NON-RADIABLE TUBE BOXWITH A DIAPHRAGM Plate 21 … NOTE 49 — FIGURE 49 — X-LIGHT TUBE WITH- THE TARGET BETWEEN CATHODE ANDANODE SHOWING THE GIRDLE Plate 22

X-rays · Phototherapy
