Rollins, William Herbert, 1852-1929 · Boston : The University Press · leaf 670
n shutter. GS,Slide with transparent non-radiable window through whichthe X-light tube can be seen. TVA, Screw-clamping move-ment in vertical arc. TD, Terminal plate of the wire Wto generator. HRS, Hard rubber sleeve for terminal wireW. .j SAB, Sliding wooden arm supporting terminal wireand… … NOTE 156 —FIGURE 2 —DETAILS OF SUPPORT-SU- SHOWN IN FIGURE 1, PLATE 109 Plate no
X-rays · Phototherapy
Internet Archive · Medical Heritage Library · Public Domain Mark 1.0. Free to use for anything.
