Rollins, William Herbert, 1852-1929 · Boston : The University Press · leaf 676
OF THE MOUTH The figure shows an X-light concentrator in position fortreating a disease of the mouth. The end ET of non-radi-able material is placed in the mouth against the diseasedarea. By means of the handles H and HH and the move-ments in vertical arc described in the text, the opening inthe… … |Q0^ X-LIGHT CONCENTRATOR-? . & X-LIGHT REGUL ATOR, NOTE 156 —FIGURES 5 AND 6 — DETAILS OFTHE PIVOT MECHANISM OF AN X-LIGHTTUBE-HOLDER Plate 113
X-rays · Phototherapy
