Notes and sketches of an architect taken during a journey in the northwest of Europe; (1877)
Narjoux, Félix, Peto, John Frederick, 1854-1907 · Boston, J. R. Osgood · leaf 124
1 ■+ - -l. I 1-2 Fig. 72. —First Floor. (Scale, .039 inch to the yard.) 1. Porters lodge. 2. Lift. 3. Office. 4. Servants rooms. 5. Large vestibule. 6. Hall. 7. Dining-room, table dhote. 8. Breakfast-room. 9. Refreshment-rooms. 10. Store-room. 11. Reading-room. 12. Coffee-room. 13. Directors room.…Architecture
Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
