Notes and sketches of an architect taken during a journey in the northwest of Europe; (1877)
Narjoux, Félix, Peto, John Frederick, 1854-1907 · Boston, J. R. Osgood · leaf 43
3k SI K 1 L 1 Ground-plan of a House at Rotterdam.Fig. 12.—Basement. Fig. 13. — Ground-floor. Fig. 14. — First-floor. (Scale, .039 inch to the yard.) A.B. C.D.E.F. Kitchen entrance. Area. Kitchen. Coal-hole. Wine-cellar. Bath-room. G. Hall. H. Drawing-room. I. Dining-room. J. Greenhouse. K.…
Architecture
