338 LENSES … Fig. 398. -How to draw the image in a con-cave lens. througli the lens, but on producing them backwards they inter-sect at Q. QP is the imageof QP. It is virtual, erectand larger than the object. For a concave lens we havethe construction shown in Fig.398. The image is virtual, erect and smaller…
