On yacht sailing : a simple treatise for beginners upon the art of handling small yachts and boats (1904)
Day, Thomas Fleming, 1861-1927 · New York : Rudder Pub. Co. · leaf 91
\ 87 SPAR AND RIGGING PLAN OF YAWL. 1— Hull. 2— Cabin house. 3— Cockpit rail or coam- ing. 4— Main mast. 5— Mizzen mast. 6— Main boom. 7— gaff- 8— Mizzen boom. 9— gaff- 10— Main sheet. 11— Mizzen 12— Main peak halyards. 13— Main throat halyards. 14— Mizzen peak 15— throat 16— Main topping lift. 17—… … 89 SAIL PLAN OF YAWL. 1— Mainsail. 4— peak. 5— tack. 6— throat. 8— clew. 2— Mizzen. 9— peak. 10— Mizzen throat. 11— tack. 12— clew.3—Jib. 13— head. 14— tack. 15— clew.Yachts · Yachting
