On yacht sailing; a simple treatise for beginners upon the art of handling small yachts and boats (1904)
Day, Thomas Fleming, 1861- [from old catalog] · New York and London, The Rudder publishing company · leaf 91
8; SPAR AND RIGGING PLAN OF YAWL. I—Hull.2—Cabin house.3—Cockpit rail or coam-ing.4—Main mast.5—Alizzen mast.6—Main boom.7- _ gaff.8—Mizzen boom. 9- gaff,lo—Main sheet.11^—Mizzen 12—Main peak halyards. 13—Main throat halyards. 14—Mizzen peak 15— throat 16—Main topping lift. 17—Mizzen 18—Main… … SAIL PLAN OF YAWL. I—Mainsail. lo—Mizzen throat, 4— peak. 11— tack. 5- tack. 12— clew. 6— throat. 3-Jib. 8— clew. 13— head. 2—Mizzen. 14— tack. 9- peak. 15— clew.Sailing
