On yacht sailing : a simple treatise for beginners upon the art of handling small yachts and boats (1904)
Day, Thomas Fleming, 1861-1927 · New York : Rudder Pub. Co. · leaf 95
9i SAIL PLAN OF KETCH. 1— Mainsail. 7— peak. 8— throat. 9— tack. 10— clew. 2— Mizzen. 11— peak. 12— throat. 13— tack. 14— clew. 3— Fore staysail. 15— head. 16— tack. 17— Fore staysail clew. 4— Tib. 18— head. 19— tack. 20— clew. 5— Jib topsail. 21— head.22_ « tack. 23— clew. 6— Topsail. 24— head.… … 93 SPAR AND RIGGING PLAN OF SCHOONER. 1— Freeboard. 2— Rail. 3— Cabin house.4_Wheel. 5— Fore hatch. 6— mast 7— topmast. 8— truck. 9— doublings. 10— Main mast. 11— topmast. 12— truck. 13— Head of main mast and doublings. 14— Fore boom. 15— gaff- 16— Main boom. 17— gaff 18— Fore sheet. 19— peak…Yachts · Yachting
