On yacht sailing; a simple treatise for beginners upon the art of handling small yachts and boats (1904)
Day, Thomas Fleming, 1861- [from old catalog] · New York and London, The Rudder publishing company · leaf 95
SAIL PLAN OF KETCH. I—Mainsail. 17—Fore stavsail clew, 7— * peak. 4-Tib. 8— throat. 18— head. 9— tack. 19— tack. lo— clew. 20— clew. 2—Mizzen. 5—Jib topsail. II— peak. 21— head. 12— throat. 22— tack. 13— tack. 23— clew. 14— clew. 6—Topsail. 3—Fore staysail. 24— head. 15— head. 25— clew. 16- - tack.… … 93 SPAR AND RIGGING PLAN OF SCHOONER. I—Freeboard. 2—Rail. 3—Cabin house. 4_Wheel. 5—Fore hatch. 6— mast 7— topmast. 8— truck. 9— doubHngs.10—Main mast. 11— topmast. 12— truck. 13—Head of main mast and doubHngs.14—Fore boom.15- gaff.16—Main boom.17- gaff18—Fore sheet. 19— peak halyards. 20— throat…Sailing
