On yacht sailing; a simple treatise for beginners upon the art of handling small yachts and boats (1904)
Day, Thomas Fleming, 1861- [from old catalog] · New York and London, The Rudder publishing company · leaf 93
SAIL PLAN OF YAWL. I—Mainsail. lo—Mizzen throat, 4— peak. 11— tack. 5- tack. 12— clew. 6— throat. 3-Jib. 8— clew. 13— head. 2—Mizzen. 14— tack. 9- peak. 15— clew. … SAIL PLAN OF KETCH. I—Mainsail. 17—Fore stavsail clew, 7— * peak. 4-Tib. 8— throat. 18— head. 9— tack. 19— tack. lo— clew. 20— clew. 2—Mizzen. 5—Jib topsail. II— peak. 21— head. 12— throat. 22— tack. 13— tack. 23— clew. 14— clew. 6—Topsail. 3—Fore staysail. 24— head. 15— head. 25— clew. 16- - tack.…Sailing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
