On yacht sailing : a simple treatise for beginners upon the art of handling small yachts and boats (1904)
Day, Thomas Fleming, 1861-1927 · New York : Rudder Pub. Co. · leaf 93
89 SAIL PLAN OF YAWL. 1— Mainsail. 4— peak. 5— tack. 6— throat. 8— clew. 2— Mizzen. 9— peak. 10— Mizzen throat. 11— tack. 12— clew.3—Jib. 13— head. 14— tack. 15— clew. … 9i SAIL PLAN OF KETCH. 1— Mainsail. 7— peak. 8— throat. 9— tack. 10— clew. 2— Mizzen. 11— peak. 12— throat. 13— tack. 14— clew. 3— Fore staysail. 15— head. 16— tack. 17— Fore staysail clew. 4— Tib. 18— head. 19— tack. 20— clew. 5— Jib topsail. 21— head.22_ « tack. 23— clew. 6— Topsail. 24— head.…Yachts · Yachting
Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
