an useless. These heaters are provided with double flues to utilize the heatof the smoke in the manner already shown in Figs. Ill, 11*2, and 115. Figs. 117 and 1 IS show a Yankee method of treating the Gallon fluein a ••tasty manner. The outer pipe takes the form of an elegantstove, and is placed… … Fig. 116. Ventilating Fireplace. Redrawn fromJohnsons Encyclopaedia. 76 THE OPEN FIREPLACE. ment both artistically and economically ! In one sense the design is true,—the heat is generated by a stove below, and by a stove above it is repre-sented. But in every other sense it is false. The envelope…
