Putnam, J. Pickering (John Pickering), 1847-1917 · Boston, Ticknor and Co. · leaf 237
Fig. 195. Distributor with the Fire onthe Hearth Heater. … Figs. 196, 197. Sections. Figs. 198, 199. Sections. the pipes when necessary, but their removal will probably be attended withdifficulty as soon as they become a little rusty. A damper is placed at the T IIE 0 P E N F IR EPL ACE. 153 top of the first and third upright pipes where shown in the cuts,…
Fireplaces
