By projecting thefinal rays into the region of their apparent emanation from before the lens,we would obtain a similar increase of the virtual focal line V- F^ V- to themagnitude d^ F^ d^, and to a reversal of the so-defined ellipses, respectingtheir greatest and least diameters, as shown by the… … Fig. 31.Concavo-convex Sphero-cylindrical Lena (+ s^ r axis 90°) The combination of a convex spherical surface with the active meridianof a stronger concave cylinder creates a periscopic section which is concave;whereas the combination of a concave spherical surface with the activemeridian of a…
