Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1916)
Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 176
Plate Detail ofLocking Device Lugs Fig. 275. Diagram of Completed Iron Core Box from the double-shrink zinc template, and making the inside edge\ inch outside of the template so as to run the stock for the outsidewall from bottom to top, as shown in Fig. 276. The perspectivesketches in Figs. 275…
Patternmaking
