Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1916)

Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 190

An illustration from Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice, 1916, leaf 190
at oneend, and five or six segments fitted, glued, and nailed into thisrabbet to form the stock for the fillet. The hub should have anormal draft—| inch-per foot—and a small chamfer or roundededge on its outer end. The grain of the stock should be parallelto the axis of the hub, whether the stock… … Fig. 296. One-Half of Complete Flange Coupling 172 PATTERN MAKING

Patternmaking
