Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1921)

Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 164

An illustration from Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice, 1921, leaf 164
Fig. 260. Section Showing Small Gear Madefrom Glued-Up Stock Bevel Gears Built»Up Construction. Patterns for bevel and miter gears arebuilt as illustrated at a and h, Fig. 261. The segments are to oxerlap PATTERN MAKING 147 as shown, which is not only a saving of stock, but also saves timewhich…
