Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1916)
Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 217
ng-Cap Casting to mold the square hole in the upright position shown at d. Thisheel core and the setting of it was an expense; there was always anunevenness at the surface of the casting caused by the heel of thecore, which had to be ground smooth. To avoid these objectionablefeatures, what is… … Fig. 342. Drag and Cope Machines in Position for Melding
Patternmaking
