Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1916)
Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 227
Fig. 361. Master Pattern of Disk Fig. 3G2. Master Pattern ofClutch Jaws the pattern g into the correct position at the end of its upwardmotion. Cope Plate, The cope mold is made on a cope plate havingonly the cope core print, the locating pin for the sprue, and theflask pins. Gate. The gate pattern…
Patternmaking
