Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1916)
Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 27
ir true and unchang-ing faces, and their simpleappliances for setting andadjusting the cutter, orplane iron, to the face ofthe plane and to the re-quired thickness of shav-ings, are greatly to be preferred to the old-style wooden planes.Construction. The general construction of the iron plane… … Fig. 21. Iron Plane PATTERN MAKING 13
Patternmaking
