Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1921)
Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 28
Fig. 21. Iron Plane PATTERN MAKING 13 … Fig. 22. Section of Plane out; in all new planes this part will be found ground and sharpenedfor immediate use. The cap iron /, Fig. 22, is fastened to tlie planeiron by an adjusting screw, as shown in Fig. 23. For whetting orgrinding the cutting edge,it is not necessary to re-move the cap iron,…
Patternmaking
