Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1916)
Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 89
Fig. 143. Right-Angle Test of Circle 72 PATTERN MAKING … Ripping Fence remaining wood being removed with the round plane and finishedwith the cylinder and sandpaper as before. If the machine-saw table can be tilted, as in Fig. 97, Part I,a cut similar to that in the previous method can be made, Fig. 145. Turning Tapered Section. The ta-pered end of the…
