Builder's architectural drawing self-taught : containing descriptions of drawing instruments and accessories, with rules for using them, and hints as to their care and management ... (1903)
Hodgson, Fred. T. (Frederick Thomas), 1836-1919 · Chicago : F.J. Drake & Co. · leaf 222
Fig. 194. 178 ARCHITECTURAL DRAWING SELF TAUGHT They are, In fact, the cyma recta repeated, the depth being lessened in Fig. 195. Fig. 196 Is a study of the elementary lines of a running scroll, formed of the wave-line, with the addition of spirals.Care must be takenin drawing these spi-rals, so… … Fig. 195.
Architectural drawing
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
