Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1916)
Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 94
Fig. 150. Finished Bronze BearingFlanged at Both Ends Fig. 151. Pattern for Bushing,Fig. 150 edge of each straight and at right angles to its face side, with themarking gage draw a center line on each, not only on the face butalso across each of the two ends, Fig. 152. Place about \ inch ofthe…
