Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1921)
Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 139
de of a, as W ^ 0 ^S Fig. 212. Turued-Up Flanges and Core Prints shown by the dotted line, and the side of a at e cut away to the samecurve as b, giving the same results as in the former method. Pipe Elbow. The pattern for the 2-inch elbow, Fig. 209, isanother illustration of how such work may be… … Fig 213. Ck)n8truclion of Ci>re Box for Eibow Fining To construct the double pattern, a ring is first turned like Fig, 211,a cross-section of which is a semicircle, as shown in the lower right-hand corner of the drawing. This ring is cut into quarters, and thefour pieces e, e, e, and e make the…
Patternmaking
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
