Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc (1919)
Fairfield, Howard Parker, 1858-, Kenison, Ervin, Waite, Edward B. (Edward Broughton), 1873-, American Technical Society · Chicago, American technical society · leaf 346
l Fig. 177. Oblique View of Hollow Cylinder inclined piece and the front edge of the bottom piece, Fig. 181.From this point draw a dotted line parallel to the length. Thehorizontal distances from the upper left corner to the dotted perpen-dicular are then marked off on this line. From these points… … Fig. 178. Oblique View of a Miter Joint
Mechanical drawing · Blueprinting
