High school manual training course in woodwork, including cost of equipment and supplies and studies on trees and wood (1905)
Ritchey, Samuel Edward, 1866- · New York, American Book Company · leaf 201
cast in great numbers, a double pattern ismade, the core being held up by the connecting part atA (Fig. 363). Construction After fitting and gluing in the dowels, turn the core-prints and end parts in one piece (Fig. 364); turn alsoa short dowel on ends, to be glued and screwed into turn. The turn… … 200 PATTERN MAKING turns to the dotted lines, clamp them together care-fully, two and two, and bore for the f in. dowel in theends. These are then glued in place, and furtherstrengthened by a small wood screw (Fig. 367). The core-box is also turned from lumljer glued up so 1 ji i )^ -
Woodwork (Manual training) · Cabinetwork
