Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1921)
Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 171
f the patternB were to be set with the edges a a resting upon the molding boardand the sand of the drag rammed down upon its upper face, it wouldbe sprung out of shape. To avoid this the follow board A is madeto exactly fit the imder side of the pattern. Then when the sand isrammed, the whole… … w H -I 50 (S ^ PATTERN MAKING PART III COMPLICATED PATTERN CONSTRUCTION HAND= AND MACHINE=MOLDED EXAMPLESHAND=/VlOLDED HYDRAULIC TURBINE Conditions, This class of work requires a very clear concep-tion of the principles of pattern making. The working drawingsare for the completed casting as usual,…
