Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1921)
Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 213
ate, A perspective view of the* stripping platefor the cope machine is illustrated in Fig. 334. The angle and dimensions of the recess Jin the top are determinedfrom the original drawing.Fig. 308, and from thelocation of the patterns onthe machine. A finishallowance of | inch should Fig. 333. Forge…
