Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1921)
Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 213
Fig. 334. Pattern for Cope Machine Stripping Plate cope stripping plate isshown in Fig. 335. Coring. The coreprints must be accuratelyplaced, and the lengthand width shall beslightly smaller than thefinish sizes to allow forthe accurate alignmentof the metal patterns,and the cored hole sho uldbe… … Fig. 335. Core Box for Cope Stripping Pkte PATTERN MAKING 195 pieces of cast iron or steel, D, Fig. 331, are fastened to the topof the stripping plate with flat-head machine screws. Drag Stripping Plate. Cope the parting to the top of the pat-tern, and a recess to match this is planed in the top of…
Patternmaking
