Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1921)

Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 214

An illustration from Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice, 1921, leaf 214
Fig. 336. Pattern for Drag Machine Stripping Plat© stripping plate, as shown by the dotted line L in Fig. 336. Thesefeatures are also to be seen in Figs 329 and 330. Stop-offs should be screwed to the underside of the stripping-plate pattern, Fig. 334, as the pattern will be weakened by cutting … Fig. 337, Core Box for Stripping Plate out the stock at J. This recess J can also be made with a dry-sand core if it is desired not to weaken the pattern as suggestedabove. 196 PATTERN MAKING

Patternmaking
