Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1921)
Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 215
Fig. 339. Pattern for Part F, Fig. 329 … Fig. 340. Master Pjattern of Gate for Holder Frame Cover by coring. The core print is to be made first and the other partsnailed and glued to it. Use great care to have all parts very accurate,keeping the dimensions slightly over size, for the exposed portions PATTERN MAKING 197 will be…
Patternmaking
