Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1921)
Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 49
Fig. 73. Typical Pattern Makers Hammer in pine and other soft woods. It is true that the mallet head willnot last so long if made of beech or maple wood, but the chisel and gouge handles will beprotected, which is amatter of much greaterimportance. Screwdriver and A2vls.Of the screwdriver,… … Fig. 74. Mallet iri3n> Fig. Ordinary Screwdriver ^^=0 The scratch awl. Fig. 76—although but little employed at the work bench, where a knife isused in its place for all accu-rate markings—is indispen-sable to the pattern maker forlaying out the dimensions on his work while it is revolving in…
Patternmaking
