Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1921)

Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 61

An illustration from Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice, 1921, leaf 61
made to slide, while the wholetable can be tilted to anangle of 45 degrees, and will remain in any position desired withoutclam-ping= As shown, it is provided with adjustable gages for cross-cutting or mitering, and with an adjustable fence for ripping, all ofwhich are removable at will, leaving… … Fig. 06. Plan of J5aw Tabl< PATTERN MAKING 47 The single-arbor circular-saw bench, shown in Fig. 97, is a lessexpensive machine than that just described; but the time lost inhaving continually to change the saw on the single arbor from ripto crosscut and back again for pattern work is a very…
