Fig. 105. Hollow Cylinder Fig. 106. Cylinder Split Pattern withCore Prints hollow cylinder is shown in Fig. 106, which, as wdll be seen, repre-sents the cylinder only externally by the part A, The core prints,one on each end of A, are represented by x and y. These projectionsform part of the… … Fig. 107. Half-Core Box
