Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1921)
Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 94
. 150 Finished Bronze BearingI^langed at Both Ends Fig. 151. Pattern for Bushing,Fig. 150 edge of each straight and at right angles to its face side, with themarking gage draw a center line on each, not only on the face butalso across each of the two ends. Fig. 152. Place about J inch ofthe pointed…
Patternmaking
