Perspective and geometrical drawing : adapted to the use of candidates for second and third-class teachers' certificates (1887)
McGuirl, Thos. H. (Thomas H.) · Toronto, Ont. : W. Briggs · leaf 69
ns fixed. A cone is formed by the revolution of a right-angledtriangle around one of the containing sides, which remainsfixed. A cylinder is formed by the revolution of an oblong aroundone side, which remains fixed. A spheroid is formed by the revolution of a semi-ellipsearound one of the axes,… … THE CUBE. 07 Example 1.—Draw a cube, edge 4, placed on G.P., one sideparallel to P.P. and 2 within it, near angle 3 to right. H = 6, L.D. = 4, scale J* = l,i Draw B.L., H.L., and 0, C.Y. and find MP as before.Take A 3 to right, and B 4 to right of A ; take C 2 to leftof A, and D 4 to left of C;…
Geometrical drawing · Perspective
