Perspective and geometrical drawing adapted to the use of candidates for second and third-class teachers' certificates (1887)
McGuirl, Thomas H. [from old catalog] · Toronto, W. Briggs; · leaf 111
Fig. 66. … In first, let AB be the given line; erect at A a perpendicularand make it equal to AB; with centre C and distance CAdescribe arc AD; with centre B and distance BA describe GEOMETRICAL DRAWING. 107 arc to meet former arc in D; join CD and BD, completingthe square. (Fig. Q6,) . (b) On a given…
Geometrical drawing · Perspective
