Perspective and geometrical drawing adapted to the use of candidates for second and third-class teachers' certificates (1887)
McGuirl, Thomas H. [from old catalog] · Toronto, W. Briggs; · leaf 73
0; join A C.Y., D MP andC MP, cutting A C.Y. in F and E. On AB describe squareASMB; join S C.Y., M C.Y. and B C.Y.; through E and Fdraw parallels to AS, meeting S C.Y. in H and G; throughG, H draw parallels to SM, meeting M C.Y. in K and L.Draw LN from L J_ to MB, and EN from E parallel to AI5.This… … The plinth differs froma cube only in the rela-tion of its dimensions;the principle employedin drawing them is thesame, but a particularside of the plinth is men-tioned in reference tothe P.P. or G.P. In thecube this is quite un-necessary, as all the sidesare equal.oi Example 1,—Draw a.fcjD plinth…
Geometrical drawing · Perspective
