The practical application of the slide valve and link motion to stationary, portable, locomotive, and marine engines : with new and simple methods for proportioning the parts (1897)
Auchincloss, William Stuart, 1842-1928 · New York : Van Nostrand · leaf 142
ys equals doublethe angular advance. Although this construction does notclaim strict accuracy, it will be found to answer all practi-cal purposes. APPLICATION OF LINK NO. II. For illustrating the process of manipulation peculiar tothis form of link, we will assume the following terms :Crank and rod…
Steam-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
