one side of the center posi-tion, or half its total travel in full gear, and which wewill designate b, when we have: tW q2_o2 rV a2-c2 = —— for outside admission, and b=—— R+c K—c for inside admission valves, where a is the radius of aneccentric that would give the required travel of the valve,and… … COCOCO rf H ti > 75^ LOCOMOTIVE ENGINEERING With the limited amount it is advisable to allow inraising or lowering the link block in reversing the mo-tion, we can without practical error consider the halfmovement of the link block g to be the same as that ofpoint F, and by limiting the angle of…
