The practical application of the slide valve and link motion to stationary, portable, locomotive, and marine engines : with new and simple methods for proportioning the parts (1870)
Auchincloss, W. S. (William Stuart), 1842-1928 · New York : Van Nostrand · leaf 124
ensionsmust be affixed, their adaptabilitytested and modified by circum-stances, and finally all must beunfolded and developed in per-fect harmony. When the sub-ject of scheming the link motioncomes in order, we find that pe-culiarities of detail have already fixed the ratio of the crank arm to the… … 110 LINK NO. I. gibly presented when the mind is able to follow their ope-ration in the solution of a practical -example, we will takefor illustration of our method the following dimensions : Ratio of crank to connecting rod—1: 7J.Eccentric circle diameter=5 J inches.Maximum cut-off=0.92…
Steam-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
