ays equals doublethe angular advance. Although this construction does notclaim strict accuracy, it will be found to answer all practi-cal purposes. APPLICATION OF LESTK NO. II. For illustrating the process of manipulation peculiar tothis form of link, we will assume the following terms :Crank and… … APPLICATION OF LINK NO. II 133 By a construction like that of Fig. 42, an angular ad-vance of about 16° and eccentric circle of 6| inches diameterare found to conform with the above conditions. If nowthe connecting rod and link motion act directly on the pistonand valve the initial position of the…
